Raditeq RadiField® 6 GHz – 18 GHz @ 75 V/m (1m)

RadiField 6 GHz – 18 GHz
75V/m one Meter Equivalent
Electric field generator 6 GHz – 18 GHz

Specifications

  • Frequency range: 6 GHz – 18 GHz
  • One meter Efield:75 V/m
  • Max. input power: +10 dBm (Typical 0dBm)
  • input connector: N-type

For further technical specifications, please refer to datasheet

Standard delivered including

  • RadiField RFS2018B Electric Field Generator
  • N-type Cable
  • RadiField protective case

Upgrade options

  • RadiCentre: Plug-in cards the RadiCentre® can be used to make integrated EMC systems
  • RadiGen: The range of RF signal generators up to 6 GHz for EMC applications

Category:

Related products

Key Features

The patented RadiField® Triple A is a revolutionary concept that caused a paradigm shift in the world of EMC immunity testing when it was introduced in 2015. The RadiField® system consists of a combination of high level integration and a lossless field combining techniques. This makes several discrete components with high power losses like combiners and external cabling superfluous.

Conventional testing

Conventional radiated immunity testing system involve a broadband amplifier and antenna. Including inefficient internal power combiners, directional couplers, two RF power meters and interconnecting cables. The efficiency of such a setup is poor at high frequencies due to severe power loss in the combiners and in both the internal and external cabling from the amplifier.

Eliminate loss

By removing all components that cause the power loss and integrating all the other components into one single instrument, all these unwanted power losses are eliminated. The RF carrier signal towards the RadiField® unit is transmitted in low power over the standard N-type coaxial cable and re-amplified before it reaches the internal power amplifiers. Thus a virtual lossless transmission between the signal generator and the RadiField® is achieved.

Active Antenna Array

At the same time the RadiField® makes use of a field combining technology with use of an Active Antenna Array. Integrated amplifiers are directly connected to the same number of integrated antennas, making a discrete inefficient combiner superfluous. Thus instead of combining power the RadiField® combines field.

Revolutionary and yet full compliant design

Although the approach was revolutionary, it is full compliant with all international EMC immunity standards. These standards solely prescribe aspects like frequency, field strength and homogeneity, which is exactly where the RadiField® is adhering to.

Low cost of ownership

The new RadiField® Triple A is not only cost effective due to its much lower price but also due to its easy installation, low power consumption, less mechanical wear and tear of cables and connectors and even more important, lower calibration cost. All these aspects result in a substantially lower cost of ownership of this immunity system.

Flexible

Due to its small dimentions, low weight and easy setup, the RadiField® can be easily moved between different
rooms and/or locations.

RadiCentre Integration
The RadiField® Triple A is easily combined with a RadiCentre® modular test system. The RadiCentre® contains the RadiSupply® plug-in card which powers the RadiField® over a standard coaxial cable running from the RadiCentre® to the RadiField®. The same cable is used to drive the carrier signal and to provide bidirectional control communication with the RadiField® unit. The RF signal may be generated either by an external RF signal generator or by an integrated RadiGen® signal generator. Finally the control of the automated H/V positioner is arranged over the same coaxial cable. The RadiField can be used with the RTW2000A mast, enabling automated polarization of the radiated field.

Broad Range

The RadiField® Triple A approach covers frequencies ranging from 800 MHz up to 18 GHz and homogeneous fields up to 100 V/m!
